Displacement
449.5 cm³
Maximum Power
31 kW / 8500 rpm
Maximum Torque
42 Nm / 6500 rpm
Length x Width x Height
2210 x 870 x 1380 mm
Wheelbase
1505 mm
Seat Height
800 / 820 mm (optional)
Fuel Capacity
17.5 L
Curb Weight
175 kg
Front Tyre
90/90 R21 CST
Rear Tyre
140/70 R18 CST
Front Suspension
KYB, φ41 upside down suspension, compression and damping adjusatble
Rear Suspension
KYB, multi-link rear suspention, preload, compression and rebound adjustable
Front/Rear Suspension Travel
200 / 200 mm (shock travel)
Front Brake
320mm single disc, four-piston caliper, J.Juan
Rear Brake
240mm single disc, single-piston caliper, J.Juan
ABS
BOSCH dual-channel ABS (rear ABS switchable)
